LATEST RELEASE
 Ultra-low noise amplifier for frequencies of 17 GHz to 21 GHz with gain >+45dB and a noise figure <1.4dB typical (<1.1dB from 17
GHz to 20 GHz). It consists of waveguide input (optional K connector input available), female K connector output, multiple low noise amplifier stages,
integral equalizer, and a built in thermoelectric cooler. The K-Band Ultra-Low Noise Amplifier is suitable for both commercial and military SATCOM
applications.
Model: A261001-1 view data sheet |
More Products from Micronetics
| Micronetics Corporation |
| Enon Microwave |
| Microwave Concepts |
| Microwave Video Systems |
| Stealth Microwave |
| About |
| Press Releases |
| Investor Information |
| Careers |
| Multifunction Microwave Modules |
| Custom Multifunction Modules |
| Frequency Converters & Multipliers |
| Switch Filters & Matrices |
| Broadband Amplifiers |
| Build-to-Print Services |
Design and Manufacturing
From Concept-to-Production
Micro-Con has a vast amount of experience designing, developing, and manufacturing state-of-the-art, highly reliable, broadband (multi-octave) microwave components and complex integrated subassemblies used in military and high-end commercial applications.
Our design expertise includes:
• Custom MMIC Chips
• Multi-layer LTCC Substrates
• Single Function MIC Devices
• Broadband Amplifiers
• Filters
• Oscillators
• Multipliers
• Multi-function Modules
• Switched Filters
• Frequency Synthesizers
• Receivers & Converters
• RF Distribution Networks
• Complete RF Subsystems
Multi-function Products
Highly Reliable Broadband Multi-function Products
Frequency Converters & Multipliers
Multi-channel Broadband RF Front-Ends and Converters with Integral Synthesized LO’s for Applications such as Electronic Warfare and Airborne DBS.
Switched Filters & Switch Matrices
2 to 8 channel Switched Filters using both PIN diode and MMIC FET switch technologies. Both Planar and Cavity Filter technologies. Switch Matrices for Signal Distribution.
Multi-function Modules to Meet Your Custom Needs
Complex Modules based upon your Custom Specifications. Adaptive Notch Filters, Phase Control Units, Switched Amplifiers, and more.
Assembly & Test Services
Build-and-Test-to-Print Services
Leveraging off of our expertise developing and manufacturing complex multi-function devices, Micro-Con offers built-and-test-to-print services for your existing
components and subassemblies that, because of their complexity, cannot be easily outsourced to other contract manufacturers.
All of our manufacturing and test operations are performed in our state-of-the-art, class 10,000 clean room. Our manufacturing processes include vacuum lamination for substrates, chip-and-wire assembly, surface mount solder assembly, and hermetic sealing.
All electrical test stations are automated and capable of performing all typical RF measurements over a -65°C to +125°C range. ESS screening is performed 100% in-house in full compliance with MIL-PRF-38534.
